Home 4G Smart Temperature measuring helmet camera with Android 7.1Bluetooth4.0 GPS

Brand Name : OEM

Model Number : OX-ZP620T

Certification : CE ROHS FCC

Place of Origin : China

MOQ : Negotiable

Price : Negotiation

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 100000/Month

Delivery Time : 5-8 work days

Packaging Details : Neutral

Product Name : 4G helmet

Display : 2.4 inches T FT

Frame Rate : Android 7.1

WiFi : Support 802.11b/g protocol，2.4GHZ

Contact Now

Parameters

Technical parameters
thermal imaging parameters	Uncooled infrared focal plane detection
	Pixel:320X240
	Viewing angle: 45-50 degrees 6.52mm f1.18 Minimum focal length: 0.5 meters
	Thermal sensitivity: 0.1 degree
	Frame rate: 9Hz; wavelength range: 8-14um
	Measuring range: -10 +330 degrees
	Measurement accuracy:-+ 0.5 degrees (32--42) + -2 degrees: 100 degrees + -1% above 100 degrees
	Display :2.4 inches T FT
System	Operation system:Android 7.1
	Processor:MTK6739 Quad-core ARM@Cortex-A53 MPCore
interface	Video interface:mipi
	Data interface:USB2.0 micro
	Power interface:TYPEC
Visible Optics camera	Foucus range:0.5 Meters----Infinty
	Angle of camera:120 °
	Photo: 16MP JPEG format
Other details	Distance of night vision:The human faces can be seen at 10 Meters in a totally black environment
	Working time: standby more than 25h, camera work more than 5h
	Waterproof:IP66
	Lithium battery :5000mAh
	Built-in one laser, accurate positioning camera target without deviation
Video	Video coding resolution	1080P/720P mp4Format
	Video FPS	1080P@30fps /720@30fps
	Video bitrate	256kbps-8Mbps
Wireless connected	WiFi	Support 802.11b/g protocol,2.4GHZ
	3G/4G	Support
	Frequecy band	TDD:B38 B39 B40 B41 FDD:B 1.3.5.8.4.7.28B
	Bluetooth	BT4.0
Physical characteristics	Weight	About 620g
	Dimension	(LWH) 280140220mm
	Working temperature	-30°C to +70°C
Management software	Real time play	support real-time 160 way data
	Beidou/GPS	Same Smarteye screen can check up to 256 camera position tracking
	Data upload	support D1 H.264 data upload
	Wireless intercom:	Real time 4G network wireless intercom,Multi person meeting
	4G upload:Real time uploaded function
	Data of real time uploaded can be checked in the platform
White light parameters	Voltage	2.85-3.6V
	Electric current	350MA-1A
	Color temperature	5000-10000K
	Luminous flux	MAX 250lumen(@1000mA)
	Beam angle	115-130°C
	power	1W
	Light distance	Maximum 10M

Home 4G Smart Temperature measuring helmet camera with Android 7.1Bluetooth4.0 GPS

Our Services

Our products warranty is 1 year.
We provide free repairing or replacement of products if the goods have any quality problem within the Warranty period.
We provide durable maintenance and Tech support service.
We will work with you to solve any problems.
Custom Development.Products can be customized according to your request and support solution of product include hardware and software.Welcome you to contact us!
